StarTech.com RS232EXTC1 Network Extender Networking

Product Name: Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)

Brand:StarTech.com

Part Number (MPN): RS232EXTC1

GTIN (EAN/UPC): 0065030841863

Categories: Network Extenders

CPIN:922921

£149.6
Per unit, single order
Ordering multiple units? Get a custom quote.

Reviews

0.0

0

Reviews

5 Star
4 Star
3 Star
2 Star
1 Star

Loading...

Description

Product Features:

  • Network receiver 1000 m
  • 10/100Base-T(X)
  • Silver

Warranty: 2 Year Warranty

StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)

Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)

Extend an RS232 serial connection up to 1000 meters (3300 feet) using Cat 5 cabling
The RS232EXTC1 Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit. The Extender is a cost-effective serial extension solution and completely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling. Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps. Backed by a StarTech.com 2-year warranty and free lifetime technical support.
The StarTech.com Advantage
- Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length
- Pure hardware design, no software or drivers required ensuring a simple plug and play installation
- Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located

StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters), Network receiver, 1000 m, Cat5, 10/100Base-T(X), Silver, 0.055 A

StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters). Type: Network receiver, Maximum transfer distance: 1000 m, Cable types supported: Cat5. Cabling technology: 10/100Base-T(X). Product colour: Silver. Input current: 0.055 A, Output voltage: 9 V. Width: 34 mm, Depth: 92 mm, Height: 22 mm

Specification

Performance

Type
Network receiver
Maximum transfer distance
1000 m
Cable types supported
Cat5

Network

Cabling technology
10/100Base-T(X)

Ports & interfaces

Ethernet LAN (RJ-45) ports
2

Design

Product colour
Silver

Power

Input current
0.055 A
Output voltage
9 V

Operational conditions

Operating temperature (T-T)
0 - 70 °C
Storage temperature (T-T)
0 - 85 °C
Operating relative humidity (H-H)
0 - 95%

Weight & dimensions

Width
34 mm
Depth
92 mm
Height
22 mm
Weight
65 g

Technical details

Sustainability certificates
RoHS

Packaging data

Package width
57 mm
Package depth
315 mm
Package height
138 mm
